Elevated Flares
Our advanced systems can be classified according to their structural support:Our advanced systems can be classified according to their structural support:
Self-Supporting
Guy wired
Derrick Guy wired
Derrick
The height of Flare Systems is determined according to the limit imposed on ground radiation when the system is in operation: the lower the imposed ground radiation value, the higher the flare system at a given mass flow rate.
Ground Flares
Open Ground Flares are featured by the following main characteristics: Suitable for elevated quantity of emergency gas discharge Smokeless functionality at any instant flow rate Versatile functions
The External Gas Distribution system
relevant to each flare stage is composed of a set of automatic and manual valves completed with a safety system (burst disc or pin valves) and the relevant block valves. These components are located outside of the flare protection shield in a free access area. The Internal Gas Distribution system is composed of a set of underground or protected gas header distributors.
